This series of impact acceleration sensors feature light weight, high stiffness, fast response, and wide frequency response, and are suitable for impact, collision, explosion testing and other related applications.

Dynamic characteristics
Measuring range	±10000
Sensitivity	0.5pC/g
Amplitude linearity	+5%
Frequency response (+1dB)	1-10,000Hz
Installation resonant frequency	40KHz
Operating temperature	-20℃~+80℃
Dimensions	φ13mm x 28mm
structure type	Ceramic shear
Install ground insulation	≥10^9Ω
Housing material	Titanium alloy
output method	Overall line/M5
Installation method	M6x0.75
weight	10克
